Vertical Band Saw
Exceptional Miter Cutting for Heavy-Duty Applications
The V-25’s standard 6° degree fixed canted head, recommended when cutting larger beams, structural steel, and bundles of square tubing allows for more efficient cutting and improved blade life.
A heavy duty vertical saw, the V-25 efficiently cuts both solid and structural material and is extremely versatile for many different types of sawing applications.
Standard Features
6° canted head allows for efficient cutting and improved blade life
Digital angle display
Powered movable guide arm
Cast iron band wheels
Robust steel base
Blade breakage switch
Replaceable carbide guide inserts
Safety door interlocks
Laser light & Work light
Control provides hydraulic powered mitering from 60° left to 60° right
Two full stroking hydraulic vises
10 HP VFD. True direct blade drive – no belts/pulleys
Replaceable blade brush
Easy access electrical panel and hydraulics
Hydraulic band tensioning with digital readout
3 HP hydraulic pump provides system pressure
Flood coolant with wash down hose
Variable vise pressure
